Cnc XK6040 horizontal milling machine for metal

  • Cnc XK6040 horizontal milling machine for metal
  • Cnc XK6040 horizontal milling machine for metal
  • Cnc XK6040 horizontal milling machine for metal
  • Cnc XK6040 horizontal milling machine for metal

Cnc XK6040 horizontal milling machine for metal

    Unit Price: 12000~20000 USD
    Min. Order: 1 Set/Sets
    Packaging: protective film package,if necessary we could packed as customs*s request.
    Productivity: 10 SETS PER MONTH
    Brand: DML
    Transportation: Ocean
    Place of Origin: CHINA
    Supply Ability: 10 SETS PER MONTH
    Certificate: ISO
    HS Code: 8459619000
    Port: SHANGHAI,NINGBO,QINGDAO

Basic Info

Model No.: xk6040

Product Description

Universal milling and drilling machine is a kind of general metal cutting machine tool.
Spindle taper hole of the machine can be directly or through the attachment installed all cylindrical milling cutter, disc cutter,
molding cutter, end milling cutter tool, suitable for processing a variety of small parts of plane, inclined plane, grooves,

holes, and other gear


8

Horizontal Milling Machine features:

1.CNC horizontal milling machine is good rigidity, can bear heavy load cutting work.
2, CNC horizontal milling machine with enough power and wide range of spindle speed. High speed cutting can be made by using hard alloy cutter, and the cutting efficiency can be fully played.
3, the spindle speed has impulse device, easy to change, the machine can quickly and effectively brake.
4, machine tool and important mechanical parts are manufactured from the alloy steel, easy to wear and tear of the parts are made of wear resistant material, Plastic guide rail , to ensure the machine has enough service life.
5.CNC horizontal milling machine three motion are limiting device to ensure the safety of workers and machine tool, but also can be used as the multi machine tool management.
6, CNC horizontal milling machine has a perfect lubrication system, Important transmission parts and bearings have perfect lubrication device,At the same time an set indicator for Conduct regular inspection
7, Good reliability, economical and practical


A5A4A3A2A1

Horizontal Milling Machine parameters:

Specifications

Units

XK6040

Table size

mm

1700x400

Table travel (X.Y.Z)

mm

920x380x350

T-type slot numbers / width /space

mm

3-18-90

Max. load working table

kg

500

Distance from spindle axis to table

mm

30-410

Distance from column vertical guide way to the center of table

mm

275-625

Rapid feed speed(X.Y.Z)

mm/min

6000/3000/6000

Feed speed (X.Y.Z)

mm/min

6-3200/3-1600/6-3200

Spindle taper

ISO50(7:24)

Spindle speed range

rpm

30-1500(18 steps)

Spindle motor power

KW

11

Longitudinal, transverse feed motor torque(X.Y)

N. m

12

Vertical feed motor torque (Z)

N. m

22

Max. spindle torque

N. m

1000

Overall dimensions(Lx W x H)

mm

2310x2200x2394

Machine weight

Kg

4250


Horizontal Milling Machine Display:

7

Horizontal Milling Machine Application:

Horizontal milling machine is available on a variety of cylindrical milling cutter, wafer type milling cutter,
angle cutter, molding cutter and milling processing of various plane, inclined plane, such as grooves.
If you use the appropriate milling machine accessories, processing gear, cam, an arc-shaped groove and a helical surface of special shape of parts,
Configuration universal milling head, circular table and indexing head and so on milling attachment,Can further expand the scope of the milling machine, this machine is applicable to all kinds of mechanical processing industry.

9
